Specifications:
● Mechanism : Stepper motor
● Syringe type: 5,10,20,30,50/60ml
● Infusion Modes: Rate mode; Time mode; Body weight mode.
● Flow rate range: 5ml:0.1~150ml/h;
10ml: 0.1~300ml/h;
20ml: 0.1~600ml/h;
30ml: 0.1~900ml/h;
50/60ml: 0.1~1500ml/h.
● VTBI: 0.1~999.9 ml, increment is 0.1 ml;
1000-9999ml, increment is 1ml"
● Accumulated volume: 0.1-9999ml
● Increments: 0.1ml/h(0.1-999.9ml/h)
1ml/h(1000-1500ml/h)
● Accuracy (± %): ≤ ±2%
● KVO: 0.1~5.0ml/h,adjustable
● Bolus rate: 0.1~1500ml/h
● Purge rate: 150-800ml/h
● Occlusion level: 3 levels
● Occlusion pressure range: Low: 300±125 mmHg (40kPa);
Medium: 525±125 mmHg (70kPa);
High: 900±180 mmHg (120 kPa).
● Screen: 3.0'' LCD monochrome screen, 240x128 pixels
● Display info.: Delivery rate, current infusion ,VTBI, total volume, syringe size, syringe brand,
pressure limit, battery capacity, drugs, remaining time, alarms
Functions
● Change flow rate during infusion
● Last configuration memory
● Front-panel lockout
● Standby
● Pause
● Silence
● Auto syringe brand recognition
● Drug Library capacity: 200
● Records quantity: 1500
● Records type: All input sand changes, infusion data
● Records stored time limit: first in, first out
● Records transmitted to PC
● Event log
Alarm
● Real-time alarm display
● Auto self-test system
● Infusion finish
● Infusion near end
● Syringes disengaged
● Occlusion
● Flow error
● Syringe unlocked
● System malfunction
● System abnormal
● Low battery
● Battery empty
● Reminder
● Standby end
● No AC Power
Interface
● Data port: RS232
● Nurse call jack
● DC input
Battery
● Battery type: Lithium
● Battery operating time: >6hrs @ 5ml/h
● Battery recharge time: ≤5 hrs
Specifications:
● Mechanism : Stepper motor
● Syringe type: 5,10,20,30,50/60ml
● Infusion Modes: Rate mode; Time mode; Body weight mode.
● Flow rate range: 5ml:0.1~150ml/h;
10ml: 0.1~300ml/h;
20ml: 0.1~600ml/h;
30ml: 0.1~900ml/h;
50/60ml: 0.1~1500ml/h.
● VTBI: 0.1~999.9 ml, increment is 0.1 ml;
1000-9999ml, increment is 1ml"
● Accumulated volume: 0.1-9999ml
● Increments: 0.1ml/h(0.1-999.9ml/h)
1ml/h(1000-1500ml/h)
● Accuracy (± %): ≤ ±2%
● KVO: 0.1~5.0ml/h,adjustable
● Bolus rate: 0.1~1500ml/h
● Purge rate: 150-800ml/h
● Occlusion level: 3 levels
● Occlusion pressure range: Low: 300±125 mmHg (40kPa);
Medium: 525±125 mmHg (70kPa);
High: 900±180 mmHg (120 kPa).
● Screen: 3.0'' LCD monochrome screen, 240x128 pixels
● Display info.: Delivery rate, current infusion ,VTBI, total volume, syringe size, syringe brand,
pressure limit, battery capacity, drugs, remaining time, alarms
Functions
● Change flow rate during infusion
● Last configuration memory
● Front-panel lockout
● Standby
● Pause
● Silence
● Auto syringe brand recognition
● Drug Library capacity: 200
● Records quantity: 1500
● Records type: All input sand changes, infusion data
● Records stored time limit: first in, first out
● Records transmitted to PC
● Event log
Alarm
● Real-time alarm display
● Auto self-test system
● Infusion finish
● Infusion near end
● Syringes disengaged
● Occlusion
● Flow error
● Syringe unlocked
● System malfunction
● System abnormal
● Low battery
● Battery empty
● Reminder
● Standby end
● No AC Power
Interface
● Data port: RS232
● Nurse call jack
● DC input
Battery
● Battery type: Lithium
● Battery operating time: >6hrs @ 5ml/h
● Battery recharge time: ≤5 hrs
